Texnik xususiyatlar va dizayn
-
Extended 30m Measuring Range: The FMR20B provides the power needed for larger storage tanks, tall silos, and deep lift stations. Its 80 GHz technology maintains a narrow beam angle across this entire range, preventing interference from narrow vessel walls or internal obstructions.
-
Heartbeat Technology: A significant upgrade for the basic segment, Heartbeat Technology enables on-demand device verification and advanced diagnostics. Operators can verify the sensor’s accuracy and health according to quality standards without interrupting the process, significantly reducing maintenance downtime.
-
Bluetooth Remote Access: With an encrypted Bluetooth connection, the device can be configured and monitored from a smartphone or tablet via the SmartBlue app. This is particularly valuable for sensors installed in hazardous areas or hard-to-reach locations like sewer shafts or atop tall silos.
-
It’s Me-Function: To ensure the correct device is being configured in a plant with multiple sensors, the “It’s me-function” triggers a flashing LED on the connected device. The integrated LED also provides immediate visual feedback on the device status (e.g., normal operation, maintenance required, or error).
-
Guided Setup Wizards: Complexity is minimized through step-by-step setup sequences. These wizards guide the user through commissioning and even the Heartbeat verification process, ensuring high-quality installation without the need for extensive manual study.
-
Versatile Solids and Liquids Handling: Beyond standard liquids, the FMR20B is capable of measuring powdery and granular bulk solids, even in pneumatic conveying systems where dust and air movement are present.
Texnik xususiyatlar matritsasi
| Xususiyat | Texnik tafsilotlar |
| O'lchov printsipi | Free-space Radar (80 GHz) |
| O'lchov oralig'i | Up to 20 m (66 ft) / 30 m (98 ft) options |
| Aniqlik | ±2 mm (0,08″) |
| Jarayon harorati | -40 dan +80 °C gacha (-40 dan +176 °F gacha) |
| Jarayon bosimi | -1 to +3 bar (-14.5 to +43 psi) |
| Aloqa | 4-20 mA HART, Modbus, Bluetooth |
| Himoya klassi | IP66 / IP68 / NEMA 4X/6P |
Standard Applications
-
Sewer and Lift Station Management: Reliable level tracking in humid and corrosive environments where ultrasonic sensors often fail due to condensation or foam.
-
Open Channel Flow: Measuring the head level in flumes and weirs to calculate flow rates in wastewater treatment plants.
-
Large Stockpiles and Bunkers: Continuous level monitoring of minerals, sand, or coal in mining and construction sites.
-
IBC and Chemical Storage: Monitoring levels in intermediate bulk containers, even through the plastic wall of the vessel.
-
Food and Beverage Utilities: Managing silos for dry ingredients like flour or sugar, and liquid storage for auxiliary fluids.
-
River and Flood Monitoring: Long-range measurement of water levels for environmental safety and early warning systems.
