ข้อได้เปรียบทางเทคนิคที่สำคัญ
-
Optimized for Non-Hazardous Areas: By focusing on applications that do not require complex explosion-proof certifications, the TM101 provides a streamlined, high-quality measurement solution at a significantly lower price point than specialized safety models.
-
Digital Integration via Bluetooth: While the sensor technology is basic, the device can be equipped with an optional Bluetooth-enabled iTEMP transmitter. This allows maintenance teams to monitor values and configure the device wirelessly using a smartphone or tablet, providing high-end diagnostic capabilities even in basic applications.
-
Enhanced Accuracy over Direct Wiring: Using a head-mounted transmitter (4 to 20 mA or HART) instead of direct wiring reduces the risk of electromagnetic interference and signal degradation over long distances, ensuring more reliable process data.
-
Robust Environmental Protection: With protection classes up to IP68, the TM101 is well-suited for outdoor installations or areas subject to heavy washdowns, ensuring the internal electronics remain dry and functional.
-
Smart Design for Easy Installation: The standard extension neck and wide variety of process connections make it easy to integrate into existing piping or tanks. Its compact and user-friendly design simplifies the initial setup for plant manufacturers and skid builders.
เมทริกซ์ประสิทธิภาพทางเทคนิค
| คุณสมบัติ | รายละเอียด |
| ช่วงการวัด | -50 to +650 °C (-58 to +1,202 °F) |
| แรงดันสูงสุด | 50 บาร์ (725 psi) |
| การออกแบบเซ็นเซอร์ | Fixed, non-replaceable insert |
| ระดับการป้องกัน | Up to IP68 |
| การจำแนกประเภทพื้นที่ | Non-hazardous (General Purpose) |
| การสื่อสาร | 4 to 20 mA, HART, Optional Bluetooth |
การใช้งานหลัก
-
Utility Monitoring: Tracking temperatures in cooling water loops, compressed air systems, and low-pressure steam lines.
-
HVAC Systems: Reliable temperature sensing for industrial heating, ventilation, and air conditioning units.
-
Machine Building (OEM): An excellent “standard” sensor for manufacturers of pumps, compressors, and hydraulic power units that require repeatable performance.
-
Food & Beverage Utilities: Monitoring non-contact secondary processes like wastewater treatment or storage of non-critical ingredients.
-
Energy Management: Providing data for heat exchangers and boiler feed systems to optimize energy consumption in non-regulated environments.
