Ключевые технические преимущества
-
Versatile Sizing and Configuration: With eight distinct configurations available, the 3024C series ensures there is an actuator size optimized for your specific thrust and travel requirements. This variety allows for more efficient sizing, reducing both costs and weight.
-
High-Thrust Casing Design: The molded diaphragm combined with high-strength casings allows for a maximum casing pressure of 6 bar. This robust rating enables the actuator to produce higher stem thrust relative to its diaphragm size compared to standard light-duty actuators.
-
Field-Reversible Action: The simple internal design allows for the change of action from direct-acting to reverse-acting (and vice versa) without the need for additional parts. This flexibility is ideal for facilities that require adaptable safety-fail modes.
-
Precision Stem Connection: Utilizing a split block stem connection, the 3024C ensures a solid transfer of motion from the actuator to the valve. This design eliminates the linkages that often lead to lost motion, ensuring accurate and repeatable valve positioning.
-
Rugged Structural Integrity: The combination of a cast steel yoke and heavy-duty steel casings provides exceptional stability and resistance to mechanical misuse. The high-quality construction materials also offer long-term protection against corrosion and wear.
-
Extreme Temperature Adaptability: Through the careful selection of specialized elastomers and metals, the 3024C can be configured to operate reliably across a wide range of ambient temperature conditions, from sub-zero environments to high-heat process areas.
-
Compact Footprint: The compact physical dimensions of the 3024C minimize the vertical space and weight load on the piping system, making it perfect for modular skid builds and tight manifold installations.
Матрица технических характеристик
| Особенность | Подробности |
| Тип привода | Spring-Opposed Pneumatic Diaphragm |
| Maximum Casing Pressure | 6 bar |
| Тип крепления | Cast Yoke |
| Stem Connection | Split Block (Zero Lost Motion) |
| Action Types | Direct or Reverse (Field-reversible) |
| Материалы | Cast Steel Yoke, Heavy-duty Steel Casing |
Основные приложения
-
General Purpose Throttling: Reliable control of globe valves in water, steam, and chemical utility lines.
-
Modular Skid Assemblies: Compact automation for oil and gas or pharmaceutical processing modules.
-
HVAC and Building Services: Precise modulation for large-scale temperature and pressure control loops.
-
OEM Equipment: Integration into specialized machinery requiring rugged, low-maintenance pneumatic thrust.
